Technical Deep Dive

Explore the architecture, build pipeline, and technical details that make ContainifyCI work.

See it in action

Here's how dunebot a real ContainifyCI project defines its entire build and CI pipeline.

engine-ci building itself
Animated demo showing engine-ci building the engine-ci project locally
1. Define your build .containifyci/containifyci.go
package main

import (
    "os"

    "github.com/containifyci/engine-ci/client/pkg/build"
    "github.com/containifyci/engine-ci/protos2"
)

func main() {
    os.Chdir("../")
    opts := build.NewGoServiceBuild("dunebot")
    opts.Application = "dunebot"
    opts.File = "main.go"
    opts.Properties = map[string]*build.ListValue{
        "goreleaser": build.NewList("true"),
    }
    build.Serve(opts)
}
2. Wire it into GitHub Actions .github/workflows/pull-request.yaml
name: Pull Request
on:
  pull_request:
    branches: [main]

jobs:
  build:
    name: Build
    uses: containifyci/.github/.github/workflows/pull-request.yml@v1
    secrets: inherit
3. Add a release workflow .github/workflows/release.yaml
name: Release
on:
  push:
    branches: [main]
    paths-ignore: ['.github/**']

jobs:
  build-and-release:
    uses: containifyci/.github/.github/workflows/release.yml@v1
    secrets: inherit

One Go file for your build logic. Two tiny YAML files to connect it to GitHub Actions. The same engine-ci run command works locally and in CI. There are no divergence and no surprises.

See the full working example at containifyci/dunebot.

Why Go instead of YAML?

YAML Pipelines Go Pipelines (ContainifyCI)
Error detection Runtime fails mid-build Compile time fails before build starts
Testing Manual / none Unit tests with go test
IDE support Syntax highlighting only Full autocomplete, refactoring, go-to-definition
Reuse Copy-paste snippets Import packages, call functions
Debugging Push and pray Run locally, set breakpoints

Architecture

Your code (.containifyci/containifyci.go)
engine-ci CLI → Compiles to single binary
Container runtime (Docker / Podman)
Isolated build steps with pinned tool versions

engine-ci reads your build definition from .containifyci/containifyci.go, compiles it into a self-contained binary, and orchestrates containers to execute each build step in isolation. Tool versions are pinned inside the containersa and not on the host machine.

Language support is modular. engine-java and engine-python are extensions that plug into the core. Adding support for a new language means writing a Go package that implements the build interface.

Build Pipeline

Every build runs through 7 orchestrated phases. Quality and Publish run concurrently for faster feedback.

Auth
PreBuild
Build
PostBuild
Quality async
Apply
Publish async

Container Runtimes

🐳

Docker

  • Multi-arch builds via buildx
  • Platform-specific image pulling
  • Registry authentication
🦭

Podman

  • Rootless containers
  • Native secrets support
  • Buildah integration
  • Manifest-based multi-arch

Auto-detection picks the available runtime, or override with the CONTAINER_RUNTIME env var.

Container Images

engine-ci builds and publishes its own container images to Docker Hub. Each build step runs inside a purpose-built image with pinned tool versions. The images themselves are built by engine-ci.

📦 Checksum-Based Tags

Each Dockerfile is hashed at compile time. The SHA256 checksum becomes the image tag, so a rebuilt image is only pushed when the Dockerfile actually changes.

⚙️ Compile-Time Metadata

Go's go:generate extracts Dockerfile content, base image versions, and checksums into generated Go code. There are no runtime parsing, errors caught before the build starts.

🏗️ Multi-Arch Builds

All images are built for both linux/amd64 and linux/arm64, so the same pipeline works on Intel and Apple Silicon machines.

🔄 Layered Image Strategy

Intermediate build images contain compilers and tooling. Production images are minimal (Alpine-based). Only the compiled binary and a non-root user.

Image Purpose Base
containifyci/golang-* Go build with linting (Alpine, Debian, CGO variants) golang:1.25-alpine / golang:1.25
containifyci/maven-* Java & Maven builds with TestContainers eclipse-temurin JDK
containifyci/python-* Python build, lint, and packaging python:3.14-slim-bookworm
containifyci/sonar SonarCloud scanner (multi-arch) alpine:3.20

All images are hosted at hub.docker.com/u/containifyci. engine-ci pulls or builds them automatically. There is no need for manual image management.

Secure Secrets

Secrets never touch disk. An in-memory key-value store with a REST API keeps credentials safe throughout the build lifecycle.

🗄️ In-Memory KV Store

HTTP REST API: secrets live only in memory, never written to disk or in the container metadata or logs

🔐 HMAC-SHA256 Auth

Request signing with timestamps and nonces prevents replay attacks

🔗 Value Resolution

mem: KV store / cmd: shell command / env: environment variable

⏱️ Session Tokens

Per-session tokens with 1-hour expiry and constant-time comparison

SSH Agent Forwarding

Unix socket bind mounts forward your host SSH agent into build containers. This enables private repository access during builds. Platform-aware for both Linux and macOS, and available across all build types.

Key Integrations

🐳 Docker 🦭 Podman 🔍 Trivy 📦 GoReleaser 🔑 Feller 🤖 Dunebot ⚙️ GitHub Actions 🦊 GitLab CI 🔐 SSH Forwarding 🏗️ Multi-Arch Builds 🔎 SonarCloud 📜 Protobuf ☁️ Pulumi
